Showcasing Our Commitment to Innovation in Treating Limb Length Discrepancies

When a self-lengthening intramedullary nail, such as an Ellipse nail, is used to help treat your child's limb length discrepancy, physical therapy is essential in ensuring a successful outcome for your child, along with an individualized care plan.

Children with limb length inequalities, along with their families and caregivers, can look forward to a family-centered, multidisciplinary approach to their care at Shriners Children’s. Each treatment plan is individualized to the child’s and family’s specific goals and needs.

Custom Treatment Plan Designed Specifically for Your Child

Shriners Children’s understands there is no “one size fits all” solution when it comes specialized pediatric care.

Your child’s surgeon will work closely with you and your care team to create the best treatment plan to help your child reach his or her goals, and to meet your needs as a family. If a surgical lengthening is recommended, your surgeon will advise whether a lengthening with an external fixator, or with an Ellipse self-lengthening nail, would be the safest and most effective option for your child.

During surgery to lengthen a bone with a self-lengthening nail, the surgeon places the self-lengthening nail into the bone, and secures it with screws at each end of the nail. With an Ellipse nail, the nail and screws remain completely inside the leg, and the parent or guardian assists with the lengthening process by using an external magnetic device according to a specific schedule each day.

Personalized Physical and Occupational Therapy

An individually designed physical therapy (PT) or occupational therapy (OT) treatment program is a critical component of any successful limb lengthening. You will most likely meet your physical therapist prior to surgery and may be given an exercise program at that time to prepare your child for the lengthening procedure. Each child’s course of therapy will include specific exercises to help stretch muscles and joints and to maximize strength as the limb is lengthened, along with functional activities to improve ease of movement and promote independent mobility and activities of daily living.

Outpatient PT or OT treatments and daily home exercise programs are prescribed while the limb is being lengthened, and continue through a subsequent period of bone healing and rehabilitation, which may continue for a total of six to 12 months on average. Some children will also benefit from a PT or OT exercise program to improve strength and mobility even before surgery, and will be provided with the necessary instruction and recommendations during a preoperative outpatient clinic appointment.

Family Participation in After-Care

Consistent, daily parent or guardian participation in each child’s after-surgery care is crucial to achieving a successful outcome. Parents or guardians participate in the following ways:

  • Carefully adhering to the daily lengthening schedule for an external fixator or Ellipse self-lengthening nail
  • Assisting your child with a twice daily home physical or occupational therapy exercise program to improve strength and range of motion in the limb being lengthened
  • Ensuring your child’s adherence to activity guidelines or restrictions to either promote bone growth or to protect a bone as instructed
  • Attending all postoperative clinic appointments with your surgeon, as scheduled
  • Attending all postoperative physical or occupational therapy appointments as scheduled

Shriners Children's Is Here For You

Children with a more significant limb length discrepancy may require more than one lengthening procedure in order to equalize the limb lengths as much as possible. Whatever your child’s treatment plan, our Shiners Children’s specialized care team, our Shriners family, is here to guide and support you through every step of your journey.

Specific treatments and services may vary by location. Please contact a specific location for more information.

Ellipse Nail Physical Therapy Instructions

Physical Therapy Phase I – Ellipse Nail

General Guidelines

patient on crutches

Activity:

  1. Non-weight bearing (no walking, standing, or kneeling) on surgical leg.
  2. Home exercise program twice daily.
  3. May use ankle weights with mat exercises under PT guidance.
  4. May pedal stationary bike with no resistance.

Note: Do not begin weight bearing on your surgical leg until your doctor advises you to do so, even after you are finished lengthening.


ellipse positioning and bracewear

Positioning/Bracewear:

  1. Wear knee brace as instructed.
  2. Lie flat on stomach at least once daily for 30 minutes.
  3. No compression garments or devices. May elevate and ice as needed for swelling.

Note: Do not modify your bracewear schedule or adjust your brace settings except as instructed to do so by your doctor.

Strengthening

wllipse ankle pumps

Ankle pumps: With leg resting on bed and knee straight, slowly pump ankle up and down as far as possible.


ellipse quad

Quad sets: Tighten thigh muscle and straighten knee as much as possible. Hold 5 seconds.
Glute sets: Tighten buttocks, hold 5 seconds.


ellipse hip abduction

Hip abduction: Slide leg slowly out to side, keeping knee straight and pointed towards ceiling.


ellipse hip rotation

Hip rotation: Gently roll leg inward and outward, keeping knee straight.


ellipse heel slides

Heel slides: Slowly bend your knee by sliding your foot as close to your buttocks as able.


ellipse short arc quads

Short arc quads: Place a firmly rolled blanket under knee, with foot resting on bed. Straighten knee and hold 5 seconds.


ellipse straight leg raise

Straight leg raise: Lie on your back with opposite knee bent. Slowly raise leg, keeping knee straight. Hold 2 seconds.

Stretching

ellipse heelcord stretch

Heelcord stretch: Pull heelbone AWAY from patient while pushing ball of foot TOWARDS patient. Hold 20 seconds.


ellipse knee extension stretch

Knee extension stretch: Gently push down on top of thigh (just above the knee) while lifting calf upward, to straighten knee. Hold 20 seconds.


ellipse hip extension stretch

Hip extension stretch: Stabilize buttocks with one hand while lifting thigh upward with other hand. Hold 20 seconds. Alternate: perform in sidelying.


ellipse hip abduction stretch

Hip abduction stretch: Take leg out to side until a stretch is felt on inner thigh. Keep knee straight and avoid leg rolling outward. Hold 20 seconds.

Physical Therapy Phase II – Ellipse Nail

General Guidelines

patient on crutches

Activity:

  1. Non-weight bearing (no walking, standing, or kneeling) on surgical leg.
  2. Home exercise program twice daily.
  3. May use ankle weights with mat exercises under PT guidance.
  4. May pedal stationary bike with no resistance.

Note: Do not begin weight bearing on your surgical leg until your doctor advises you to do so, even after you are finished lengthening.


ellipse positioning and bracewear

Positioning/Bracewear:

  1. Wear knee brace as instructed.
  2. Lie flat on stomach at least once daily for 30 minutes.
  3. No compression garments or devices. May elevate and ice as needed for swelling.

Note: Do not modify your bracewear schedule or adjust your brace settings except as instructed to do so by your doctor.

Strengthening

wllipse ankle pumps

Ankle pumps: With leg resting on bed and knee straight, slowly pump ankle up and down as far as possible.


ellipse quad

Quad sets: Tighten thigh muscle and straighten knee as much as possible. Hold 5 seconds.
Glute sets: Tighten buttocks, hold 5 seconds.


ellipse short arc quads

Short arc quads: Place a firmly rolled blanket under knee, with foot resting on bed. Straighten knee and hold 5 seconds.


ellipse heel slides

Heel slides: Slowly bend your knee by sliding your foot as close to your buttocks as able.


ellipse long arc quads

Long arcs quad: Sit with knees bent. Slowly straighten knee. Hold 5 seconds.


ellipse straight leg raise

Straight leg raise: Lie on your back with opposite knee bent. Slowly raise leg, keeping knee straight. Hold 2 seconds.


ellipse straight leg sidelying

Straight leg raise, sidelying: Bend bottom leg. Keep top leg in line with shoulder and knee straight. Lift slowly. Hold 2 seconds.


ellipse straight leg prone

Straight leg raise, prone: Lift leg, keeping knee straight. Hold 2 seconds. Optional: place pillow under hips.


ellipse hamstring curls

Hamstring curls: Slowly bend knee, bringing foot towards buttocks, until you feel a stretch. Hold 5 seconds.


ellipse standing hip flexion

Standing hip flexion: Stand with hand on a support. Lift leg forward, keeping knee straight.


ellipse standing hip abduction

Standing hip abduction: Stand with hand on a support. Tighten outer thigh and lift leg to the side, keeping knee straight and trunk upright.


ellipse standing hip extension

Standing hip extension: Stand with hand on a support. Tighten buttocks and lift leg behind you, keeping knee straight and trunk upright.

Stretching

ellipse heelcord stretch

Heelcord stretch: Pull heelbone AWAY from patient while pushing ball of foot TOWARDS patient. Hold 20 seconds.


ellipse heelcord stretch

Heelcord stretch 2: Loop towel or elastic band around ball of foot. Pull towards you until stretch is felt on back of calf. Hold 20 seconds.


ellipse knee extension stretch

Knee extension stretch: Gently push down on top of thigh (just above the knee) while lifting calf upward to straighten knee. Hold 20 seconds.


ellipse knee flexion stretch

Knee flexion stretch: Lying on stomach, stabilize hip while gently bending knee. Do not allow bottom to rise from bed. Hold 20 seconds.


ellipse hip extension stretch

Hip extension stretch: Stabilize buttocks with one hand while lifting thigh upward with other hand. Hold 20 seconds. Alternate: perform in sidelying.


ellipse hip abduction stretch

Hip abduction stretch: Take leg out to side until a stretch is felt on inner thigh. Keep knee straight and avoid leg rolling outward. Hold 20 seconds.


ellipse hamstring stretch

Hamstring stretch: Begin with hip and knee bent in a chair position. Keeping thigh in place, gently straighten knee until stretch is felt on back of thigh. Hold 20 seconds.


ellipse patellar mobility

Patellar mobility: Locate the top of the knee cap with one hand, and the bottom of the knee cap with the other hand.

  • Gently guide the kneecap downward, towards the toes. Hold ___seconds.
  • Gently guide the kneecap upward, towards the hip. Hold ____seconds.

Common Questions Kids Ask

Initially after surgery, children may feel afraid to move their limb with the ellipse nail. As the lengthening process begins, their muscles will tighten and weaken somewhat. This is to be expected. The goals of physical therapy are to help keep their muscles flexible and strong, and to help them stay as active as possible throughout the rehabilitation process.

Here are some answers to common questions and concerns your child may have.

When does physical therapy start? Physical therapists will begin working with your child the day after surgery. Your physical therapist will provide an exercise program that you will help your child perform in their room on weekends. Most children are able to go home the Monday following surgery.

If it seems too difficult... At first, your child may need help moving their limb in bed. If it involves their leg, this will include standing and taking a few steps with a walker or crutches. He or she will likely require a wheelchair to get to physical therapy. This is perfectly normal and you will work with your child to help them regain their independence. Most patients are up and walking with a walker or crutches by the time they leave the hospital, using a wheelchair only for long distances outside of the home.

How does physical therapy work? While in physical therapy, your child will work on strengthening and stretching exercises. Your physical therapist will provide an exercise program designed specifically for your child and will make recommendations on whether a walker, crutches or cane is best for them. If your child is able, your therapist will teach them how to walk up and down a small flight of stairs in the physical therapy department as well. Things may go slowly the first day or two, but it will get easier.

Will I have to do this at home? Before your child leaves the hospital, their physical therapist will ask you to demonstrate that you're comfortable assisting him or her with their home exercise program and supervising them while walking. You'll also be asked to show that you can adjust your child's ellipse nail. You will be given a written copy of your child's home exercise plan, including your therapist’s contact information in case you have any questions after you leave. It is very important that you encourage your child to continue to perform their exercise plan as instructed and follow all therapy instructions. This is the proven method to give your child the best quality of life.
